This tool helps to copy geometry of the reinforcement bars by dragging and dropping them to the expected location on any view without increasing the number of reinforcement rebars
In the structural drawings, reinforcement bars often close or partially overlap each other. This makes difficult to observe them in viewports. To overcome this issue, “drag rebars” tool allows copy geometry of the renforcement rebars to the desired position without increasing the number of rebars in the original three-dimentional model. So, users can easily see details of each reinforcement bars on shop-drawing. The above copy action is simply done by dragging reinforcement rebars and dropping them to any position on the viewport.
