Dynamo for pattern design

Recently I have been asked to demonstrate how Dynamo can help in the manufacturing market, especially in pattern generation, so I came up with this little example that can show all core Dynamo features at once: the Visual Scripting side by side with some Dynamo Script as well as some Python Nodes, Complex Geometry controlled by Parameters, Pattern generation, Lists handling, the Connection with External Resources (in this case Images) that can be used to generate information, the Export to SAT format to bring the idea in the physical world through other platforms such as Fusion 360…
