If you are utilizing Revit for electrical engineering design, then you are using electrical panels and likely electrical panel schedules. While the process of inserting electrical panels and connecting basic circuits to them is pretty straightforward, there are some items that are good to know to help you better utilize panels and their associated schedules.
First off, a requirement in this process is to make sure that after you place an electrical panel in the Revit model, you set the Distribution System for it. Otherwise, you will not be able to connect any electrical device or other electrical equipment to the panel. The Distribution System is shown in both the panel’s Properties palette, and on the Options Bar on the ribbon.
Panel Schedules in Revit are a report of the information that is contained in the electrical panel, and schedules cannot be created without having a panel family placed in the project file. They are not like a spreadsheet where the numerical…
