The latest release of Autodesk’s Advance Steel 2018 promises to both streamline the 3D modeling tool and improve interoperability with other Autodesk software, such as Revit, Navisworks and AutoCAD. This article will examine the software’s new features, and explain how they impact the architects, structural engineers and construction workers who use it.
Figure 1 – Advance Steel 2018 adds 130 parametric steel connections that may be transferred to the Revit model. Image courtesy of Autodesk
Improved Level of Detail
The first big highlight is Advance Steel 2018’s ability to offer “seamless consumption of LOD 350 Revit models.” LOD, short for “level of detail”, is defined by BIMForum as a measure of the amount of description attached to items in a Building Information Modeling (BIM) model – or example, at LOD 100, a light fixture might only have cost information, while at LOD 350, it would also include things like its geometric shape, in the form of a CAD model. The ability to read CAD models directly from Revit files should give engineers more accuracy in their designs, let them issue bills of material, and let them respond more quickly to architectural design changes.
Added Parametric Steel Connections
A second major update is the addition of over one hundred and thirty parametric steel connections. To sweeten the deal, these connections also transfer to the model in Revit to improve coordination between engineers and fabricators.
The new…
