Introduction
In the last tutorial we saw how the Wall Opening tool can be used to create very basic apertures in Revit Walls. For the vast majority of the time the openings that are created in Walls are part of a Door or Window assembly. In Revit, we have dedicated tools for creating Doors and Windows respectively. In their actual operation, both tools are nearly identical. The only difference being the category of object that they create- hence me covering the use of both tools in the same tutorial.
Unit Agenda
- Learn to place Revit Doors and you’ll know how to place Windows!
- Revit Doors and Windows are Hosted Components
- Placing a Door or Window into your Model
- Changing the orientation of your door or window
- Door and Window numbering
- Creating additional Door and Window Types
- Loading additional Door and Window Families into your Project
[youtube https://www.youtube.com/watch?v=Gg8qFOGly3E?feature=oembed&w=720&h=405]
