There are times that a Revit user will come across a family where the family creator added many types to the family. I recently talked to someone that had a family with over 100 types defined within the family. This has the following ramifications:
- It increases the size of the family.
- It creates many family types in the project that are not needed.
- It displays a long list of types in the Type Selector for the family making it confusing finding the desired type.
Fortunately, Autodesk Revit has provided us with an easy way to create a Type Catalog that contains all of the types contained within the family. This eliminates the need to have a family with a huge list of types within it. We can create the Type Catalog directly from the family, so we do not need to recreate the data contained in each family type.
To more easily describe the process, I created an example family.
Example Family Setup
For purposes of this article, I created an example family that only contains 3…
