This exclusive revit video tutorial provides the demonstration of new freeform rebar tool that is accessible in Revit 2018.1
This latest tool facilitates the users to include straight bars (Shape Code 00) which are based on complicated surfaces. The bars will produced a complicated shape but stay straight for fabrication instructions.
The Freeform Reinforcement tool is applied in a 3D view by initially choosing the host face. This tool applies the Select Multiple option. With the help of space bar, validate the selection. Then, choose the starting surface and then the ending surface and lastly press enter to set the bar.
This tool is mostly suitable while going to model complicated Architecture and Civil structures like bridges and tunnels. Each bar should have been scheduled for a precise length.
Free Form Rebar can contain any geometry in the form of planar or 3D, and can be utilized for modeling and detailing of reinforcement in complicated 3D structural elements.
Rebars are…
