Filtering is necessary when using Dynamo to select elements. For example, if we were looking for all exterior doors in a project, we would use Dynamo to grab all the doors in a project and then filter down the ones that have the type Function parameter set to Exterior. Similarly, you may want to filter out elements that meet a condition.
In the following example, you will report all the reference planes in a Revit project which have not been named.
- Create a script that will collect all reference planes in a project. You accomplish this by extracting all reference plane elements from the project.
- You then check to see which elements have no name by evaluating which ones are equal to an empty string node. This generates a list of elements that is equal in length to the number of true and false values.
- You utilize the List.FilterByBoolMask node to feed it both the list of elements and “mask” of true/false values. Essentially, if the list element matches a true, it will be allowed…
