How to create a flowing & elegant staircase in Revit

In this revit tutorial you will learn the steps for creating the design of a flowing and elegant staircase in Revit.

Given below, some useful revit stair definitions :-

BASE AND TOP LEVELS: Stairs are formed on the basis of selected levels available in the project. If necessary, any offset can be included on these levels.

REQUIRED STAIR HEIGHT: Total distance among the base and the top of the stairs along with the offsets.

REQUIRED NUMBER OF RISERS: It is measured automatically with Revit, by dividing stair height with maximum riser height. This number can be altered to change the slope of the stair.

ACTUAL NUMBER OF RISERS: The number of risers already been modeled.

MAXIMUM RISER HEIGHT: Riser height for your stair will never surpass over this value. This parameter is fixed on the stair type. Normally, equal to code requirements.

ACTUAL RISER HEIGHT: This distance is automatically computed with Revit, by dividing the stair height with the required number of risers.
