In this video I show you how to model a Parametric Tnesile Canopy in Revit!
First I set the reference planes and add all the dimensions so I can assign the parameters. Then I model the construction poles and lock them in place. Finally I model the fabric portion and save the file.
Shortcuts:
UN – Project Units
CS – Create Similar
RP – Reference Plane
Al – Align
