9 Tips To Understand Revit Roofs


Struggling to create the perfect roof in Revit? Not sure how to create a slope? Want to create a dormer window? We’ve got you covered.

This guide provides the answers to the most common roof problems beginners face with Revit. You can also watch the video tutorial below if you prefer.

1- REMOVE SLOPE TO CREATE FLAT ROOF

Want to create a flat roof? In the option bar, make sure Defines Slope is deactivated before drawing the boundary.


To turn a sloped roof into a flat roof, select all roof boundaries purple lines and uncheck Defines Slope in the option bar.


2- ACTIVATE SLOPE TO CREATE A SLOPED ROOF

Want to create a sloped roof? In the…
