Throwback Thursday – Space Shuttle Sample Drawings

Going into the Autodesk way way back machine for these AutoCAD sample drawings, the Space Shuttle Columbia from AutoCAD 2014 and Shuttle 3D DWG from AutoCAD R10.

Shuttle Columbia

Download Columbia DWG

Shuttle

Download Shuttle DWG

A favorite historic DWG of mine is from AutoCAD 1.2, but sadly the copy I have right now is unable to be opened. Here is a screen capture of the drawing when I had it at one time opened in AutoCAD 2.18.
Image result for shuttle AutoCAD sample drawing

Aside from this historic AutoCAD sample drawing, the Space Shuttle Columbia was the first space Shuttle STS-1 and after 22 years of 27 missions was tragically lost in a disaster with all 7 astronauts onboard mission flight STS-107.

I had the absolute pleasure of being invited to watch the final Space Shuttle Discovery launch STS-133, on February 24, 2011. It was one of the most amazing experiences of my life.
Space Shuttle Discovery STS-133 Launch

Amazing Space Shuttle Launch Experience

Stay tuned for more of your favorite historic AutoCAD sample drawings.

Cheers,
Shaan
