Free External Dimensions on Plan

From the ModPlus website:

External dimensions on the plan

This is a free feature!

Author:  Pecshev Alexander

The function allows you to put in one click the external dimensions on the floor plan. The function only processes horizontal and vertical walls and axes. The outer dimensions are set according to the current working configuration, which indicates the sides of dimensioning and setting of dimensional chains

[youtube https://www.youtube.com/watch?v=TgFXT82XpLU]

Available version: 1.1.0.0
