In this construction article, you will learn how to use revit for generating your own animated GIFs.
Animated GIFs are most effective while employing a consistent view point and modify something inside the view, as for example the clarity of the elements or the cutting plane of a section box. Here, the cutting plane of a section box is modified in order that the GIF can animate the movement of the section via the building.
Initially, generate the 3D view and activate the section box. It is the starting view and ensure that the section box isn’t cutting the building. This view is titled as a “_01” suffix. A new 3D view template is also generated and included to this view. This template will be applied to manage the clarity of the section box in all the animation views.
After completing it, replicate the view, move the section box into the building by about 20 feet and redefine the view with an “02” suffix.
The entire method of replicating the view, moving the section box,…
