1) CHAMFER:- It is used to produce bevel about a corner.
Activation:-
Alter Toolbar => Chamfer icon.
Alter menu => Chamfer option.
Type CHAMFER or CHA at “COMMAND:” prompt and press enter
2) PLOT :- It is applied to print the drawing on paper.
Activation:-
Ctrl+P is the shortcut key
File menu => Plot option.
At “COMMAND:” prompt, type PLOT and press enter
3) LENGTHEN:- It is helpful for modifying the length of an accessible line. It is also possible to view the length of a selected line at command prompt.
Activation:-
Alter toolbar => Lengthen option.
At “COMMAND:” prompt, type LENGTHEN or LEN and press enter
4) XLINE (Construction Line) :- It is a useful command to generate a endless line.
Activation:-
Draw toolbar => Construction Line icon.
Draw menu => Construction Line option.
Type XLINE or XL and press enter at “COMMAND:” prompt.
5) ATTDEF (Attribute Definition) :- It is applied to include block attribute to a block. An attribute stands for a label or tag that…
