I have seen the situation where the Electrical designer was working on a remodel project and did not want their Existing electrical devices to be shown in the New Construction phase views. The existing electrical devices and equipment were only to be shown on views that displayed only existing information. However, they needed to show both the Existing and New Construction walls and other Architectural elements in the New Construction views. Revit doesn’t want to do this without changing the default settings.
By default, the linked Architectural elements will show the same phase as the host Electrical file’s view.
- If the Electrical file’s view has its Phase parameter set to New Construction, and the Phase Filter parameter set to Show Previous + New, you will see the existing elements for both files as well as the new elements for both files.
- If the Electrical file’s view has its Phase parameter set to New Construction, and the Phase Filter parameter set to Show…
