As noted in a previous post about Custom Blocks for Railings, those blocks can only be attached to the Model Display Representation. While the Plan, Plan High Detail, Plan Low Detail and Plan Screened Display Representations do not allow for Custom Blocks, they do allow for Custom Profiles, which may work for showing a base plate at each post, depending upon how fussy you are about the graphics. One might first ask the question, “Do I really need to see base plates in a plan view of a Railing?” At typical plan scales (1:100, 1/8″ = 1′-0″, 1:50, 1/4″ = 1′-0″), one could make a convincing argument that the added graphic will, at best, be a slightly wider blob, with the lineweights causing the plotted linework to merge with the railing and post graphics. For the purposes of this example, lets say that for the High Detail Display Configuration/Plan High Detail Display Representation Set (Top view direction)/Plan High Detail Display Representation for Railings, we do want to show…
