Fundamentally, column layout plan is drawn with hand or AutoCAD. Given below, some useful step-by-step guidelines for column layout drawing with AutoCAD.
The following steps are involved :-
1. Select Column Shape: Initially, select the column shape. Several types of column shape are applied in diverse structures which range from circular, rectangular, box type column. Hence, it is important to select the column shape beforehand.
2. Draw the Column: As soon as the column shape is selected, then draw the column by applying the commands as rectangle (rec+Enter) or circle(c+Enter).
3. Settle the Column Location: Placement of column is considered as the most crucial part of a structure. The construction of a structure is based on the location of the column. Therefore, all the columns should be arranged at the exact location.
4. Settle the Grid Line: Gridline is a very significant segment of a structure since the position of all sections of the structure is set based on the grid line….
