It’s always a good idea to review the basics of what we do daily just in case we are missing a trick! It is all too easy to do the same as we did last week, last month, last year… In this post we look at some basic structural elements and consider how custom Revit content could be created to save time and make detailing more consistent and robust.
I often think of Revit as a digital Lego set, you have a certain number of pieces to assemble a structure, but the limitation is the variety of ‘bricks’ that are provided. For example, the three bricks below can only build simple, box like structures.
The great thing with Revit is that we can create our own parametric families that are either bespoke to a project or for use in many projects. The custom families give Revit the flexibility needed to create any type of family with fast and efficient placement into projects.
A simple example to start with is the humble pile family. All too often, the default out of the box single…
