This tutorial goes through the process of how to create Precast Hollowcore Plank Floors in Revit using the Native Revit Precast add-in tools, but also covers an alternative method if you are without access to the add in for any reason.
If you would prefer to follow along at your own pace there is a step by step guide available from the link below:
Click Link for Blog Post:
The Video Content is as follows:
00:00 – Introduction to Topic and Installation for Precast Tools
01:31 – Getting Familiar with the Precast Revit Families
05:31 – Setting up the Revit Precast Configuration Options for the Hollowcore Slab
09:00 – How to to Model a Precast Hollowcore Plank Floor in Revit
15:32 – How to notch the Revit Precast Hollowcore Floor
24:19 – Applying Dimensions and Tags to the Revit Precast Hollowcore Plank Floor
29:50 – How to automatically generate Hollowcore Plank Shop Drawings in Revit
33:19 – Aternatieve method to create a Hollowcore Slab in Revit using Beam Systems
