Displaced views can be used to illustrate the relationship that model elements have to the model as a whole. Displaced views are similar to exploded views, but provide flexibility by allowing the displacement of selected elements or all elements. This tool is available in a 3D or perspective model, when you select one or more model elements. Join ATG Technical Specialist, Brian Weeks in this Tech Talk where he shows the user how to create displacement sets in Revit. To contact Brian Weeks, Senior ATG Technical Specialist, email [email protected].
The post Tech Talk: Creating Displacement Sets in Revit appeared first on ATG USA.
