Sections in Revit are easy right? We use them everyday in our projects. Be it building sections, wall sections or details, we use them all the time and are pretty familiar with them. But there are some valuable options and settings available to us that can really boost our efficiency when creating sections. We can also Customize the look and feel of our Revit Section Lines to make them stand out. Revit Sections are easily overlooked as we use them all the time, but in this blog post I’m gonna dig a little deeper into the humble Section and reveal some things to help you work smarter.
Revit Section Lines
Did you know you can customize Revit Section Lines? They don’t have to be a continuous black line (although that’s a pretty common standard). Sometimes a solid black line can interfere with what you are trying to present on your drawings, so its nice to know we can change them if we wish. We do this by changing the Object Styles.
On the Manage tab you will find Object Styles to the…
