Revit – Complete Tutorial for Beginners – Learn to use Revit in 60 minutes – Part 6

Tutorial for Beginners in Revit. Part 6

In this part we will continue talking about Stairs and we will conver the Dimension lines more in detail.

Contents:
00:00 Intro

Stairs (cont.)
00:21 Draw stair in U-shape
01:51 Fix railing

Dimension lines
04:27 Aligned Dimensions
08:24 Auto dimension options
13:05 Constraints
14:06 Dimension equality
16:37 More dimension styles

If you have any questions or comments please feel free to post :).
Alternatively, you can send me an e-mail to: [email protected]

Licence:
The video shows the version 2020 of RevitĀ® and it is used exclusively for educational purposes.
Autodesk screen shots reprinted courtesy of Autodesk, Inc.
The narration and all the illustrations were created by CAD in Black.
