Complete tutorial for Beginners in Revit. Full tutorial 2h15.
If you want to watch this split in several videos, please click on the playlist below:
Download Floor plan used in this exercise:
Revit Libraries:
List of Contents:
Part1
00:00 Intro
06:45 Mouse (buttons and functions)
08:42 Start a new project
09:49 Place walls
13:50 Project Units
15:52 Walls (location line + wall types)
18:53 Visual styles and detail level
Part2
20:30 Walls
25:23 Manipulate walls and dimensions
30:11 Doors and Windows
34:55 Edit height of walls
Part3
37:37 Levels
44:14 Floors
51:37 Ceilings
55:05 Components
58:16 Sections
Part4 (Modify commands)
1:00:35 Copy
1:02:05 Move
1:02:27 Array
1:03:18 Rotate
1:04:19 Align
1:06:45 Offset
1:08:47 Mirror
1:11:31 Split
1:15:32 Split with gap
1:17:06 Trim/Extend Elements
1:20:05 Trim/Extend to corner
Part5
1:20:51 Hide / Isolate Elements
1:26:11 Hierarchy Terminology
1:30:41 How to Draw Stairs
Part6
1:43:46 Dimension lines
Part7
1:58:27 Roofs by Footprint
2:06:00 Grids
2:09:39 Columns
If you have any questions or comments please feel free to post :).
Alternatively, you can send me an e-mail to: [email protected]
Licence:
The video shows the version 2020 of Revit® and it is used exclusively for educational purposes.
Autodesk screen shots reprinted courtesy of Autodesk, Inc.
The narration and all the illustrations were created by CAD in Black.
