On this episode of BIM After Dark Live Brenton Wiberg returns to the show to share some of his most useful (and impressive) advanced Revit family techniques, tips, and tutorial.
Brenton will be demonstrating some of the following real-world advanced Revit family creation techniques:
– Nesting multiple windows or doors that are fully parametric but also able to be tagged and scheduled on their own…
– Dealing with parametric drawer and cabinet fronts…
– A custom door tag you WON’T want to miss…
– and more…
So sit back, relax, and let’s geek out!!
