The redline drawing is an architectural plan drawing that has been redline corrected. It is usually a plain white piece of paper that is used to draw an original drawing in black ink. Red ink is used by architects to highlight changes to designs or corrections to specific details before approval.
It is also possible for a contractor to alter an architect’s approved plan during construction. Client requests or unexpected onsite challenges can lead to changes during a construction project.
Correcting errors and proposing changes on complex technical drawings requires legible red ink. Furthermore, it must contain enough descriptive information to define the new specifications. Hand drawn redlines should avoid confusion for architects and clients.
Redline Drawing Cost
Modifications to an architect’s blueprint differ from corrections to an architect’s plan. During construction, redline drawings to correct mistakes or remove non viable elements. Revisions typically occur…
