Made a discovery today, related to the previous post regarding moving items with Disjoin checked. Once again, I failed to notice that was checked. This time I was experimenting with Copy/Monitor. I set up a structural model with some Grids. I cross-linked the structural and architectural models, and Copy/Monitored the structural grids in the architectural model, from the structural link. Then I moved one of the Grids 2′-0″ perpendicular to its length and synchronized the change.
Back in the architectural model, I reloaded the structural link and, as expected, was told that there was a Coordination Review for a link. I ran the Coordination Review for the structural link, and, unexpectedly, was told that an element was deleted (not moved!). This was confusing, because I could see the grid line from the structural link; it was there. I did it all again, with the same results. I decided that since it was after 5:00 pm, I would save my models and try again tomorrow. I went to…
